RGPS系列单缸圆锥破碎机

RGPS系列单缸圆锥破碎机是我公司吸收和消化国内外技术并结合机、电、液等研发的一款新型圆锥破碎机该设备采用了高强度铸钢机架,合金锻造主轴,高精度螺旋齿轮传动结构,结合多种冲程和腔型,使设备性能和优势得以完美体现,可以应用与多种硬岩的首段破碎作业中,充分 满足客户的多种破碎需求

服务电话:152 2543 9821

企业邮箱:luoyangruike@163.com

RGPS系列单缸圆锥破碎机

应用领域:广泛应用于金属和非金属矿、水泥、砂石、冶金等行业

适用物料:河卵石、花岗岩、玄武岩、石灰石、石英石、辉绿岩、铁矿、金矿、铜矿等

产品优势

高可靠性:优化和改进产品结构、材质、加工及装配工艺,从而上保障了主机使用时的可靠性
高生产效率:科学合理的破碎腔型、偏心距、动锥摆频及层压破碎原理相结合,通过量更大,产品粒型好、能耗低
适应性广:根据不同的进料和成品料尺寸,匹配合理的腔型,采用钢底架或电机与主机一体安装,使安装设备省时,成本更低
低运行成本:特殊设计的腔型和衬板材料,使衬板利用率更高,配备有正压防尘系统,保障主机内部润滑油不受粉尘污染
设备参数
RGP100S排料口
(c.s.s)
20
mm
25
mm
30
mm
35
mm
40
mm
45
mm
50
mm
16mm80-90105-115120-130135-145145-165155-175
20mm120-130145-155160-180170-200185-215
25mm185-195200-220210-230
RGP300S排料口
(c.s.s)
20
mm
25
mm
30
mm
35
mm
40
mm
45
mm
50
mm
18mm170-190170-210190-230210-255235-275255-295
25mm220-270255-315290-345320-350330-350
32mm360-400380-420400-440
40mm450-500480-530
RGP500S排料口
(c.s.s)
45
mm
50
mm
55
mm
60
mm
65
mm
70
mm
75
mm
18mm300-350325-375375-425400-450425-475450-500500-550
25mm500-550550-600600-650650-700700-750750-800
32mm650-700700-750750-800825-875900-950
40mm900-950970-1050

注:生产能力为含水量不超过4%、不含粘土、给料粒度级配适当,小于排料口的物料占给料总量10%以下,给料在破碎腔四周均布,物料松散密度为1.6t/m³的岩石开路设计时的通过量。在闭路作业条件下,设备能力比开路作业高15%-30%。由于所选设备偏心量、破碎比、给料硬度、给料粒度组成,给料含水量、含泥量等都会影响破碎机的生产能力,所以对具体的应用情况请向我们进一步咨询。

Note: the production capacity of less than 4% moisture content, do not contain clay, feed particle size grading, appropriate materials is less than the discharging mouth of the feeding amount is less than 10%, feeding uniformly distributed around the crushing cavity, loose material density of 1.6 t/m after the rocks when open circuit design by quantity. Under the condition of closed circuit operation, equipment capacity by 15% to 30% higher than open operation. Due to the selected device of eccentricity, crushing ratio, feeding the hardness and the grain size of feed, feed moisture content, such as hydraulic crusher production capacity will be influenced, so the specific application, please consult us further.

产品外形及重量

Product appearance and weight

型号(Model)RGP100SRGP300SRGP500S
总量kg*(Total)73501620035000
维护期间重量
kg

During the period of maintenance weight

2500520011000
尺寸(Size)
A232825463227
BΦ1300Φ1860Φ2300
C90814011587
DΦ1320Φ1820Φ2330
EΦ1360Φ1686Φ2330
F5664991275
G144215822100
H140017002225
I109014001676
J**)241625503756
J***)260032304420
电动机功率,kw

Motor power

75-90200-250200-355
冲程选项

Stroke options

16,20,2518,25,28,
32,36,40
18,25,28,
32,36,40

*):不带配件的基本机器,给出的重量带有重的破碎腔

*):Don't take parts of basic machine, given the weight of the crushing cavity with weight

**):从减震块到料斗顶部

**):From the top damping blocks to the hopper

***):从减震块到带有上机架的给料斗顶部

***):From shock block to the hopper with a rack on the top

给料口尺寸

Feeding mouth size

腔型(Cavity type)RGP100SRGP300SRGP500S
M200mm
C250mm280mm380mm
EC380mm500mm
M=中腔型,C=粗腔型,EC=特粗腔型

M = lumen, C = coarse cavity, EC = coarse cavity type
